Power

The AXIS 30 W Midspan is a reliable single-port Power over Ethernet (PoE) injector designed for indoor environments. It provides an easy, fast, and cost-effective way to supply both power and data to compatible network devices over a single Ethernet cable, reducing the need for separate power supplies and simplifying installation. Supporting both IEEE 802.3af and IEEE 802.3at standards, this midspan delivers up to 30 watts of power, making it suitable for a wide range of network devices, including cameras, access points, and other PoE-enabled equipment. With data transmission speeds of 10, 100, and 1000 Mbps, it ensures efficient and consistent network performance. The AXIS 30 W Midspan operates on a wide input voltage range of 100 to 240 volts AC and is designed for plug-and-play installation, allowing for quick setup without additional configuration. Its compact form factor and compliance with PoE standards make it a practical solution for expanding or upgrading your network infrastructure with minimal effort.

The AXIS Camera Heater Power Supply is a complete power supply kit designed to provide additional power to the AXIS Q6010-E and AXIS Q6100-E network cameras. This essential accessory enables the cameras to operate in extremely cold environments, extending their minimum operating temperature down to -50°C (-58°F). Ideal for installations in harsh, sub-zero climates, the heater power supply ensures reliable performance and uninterrupted surveillance even in the most demanding weather conditions. This power supply is also a required component when using the AXIS Q6100-E in combination with any camera from the AXIS Q63 Series, ensuring full compatibility and optimal functionality in integrated surveillance setups.

This power supply is specifically designed for the AXIS D8208-R Industrial PoE++ Switch, providing a stable and high-capacity power source suitable for industrial environments. It supports a wide range of both AC and DC input voltages, making it highly adaptable to different power systems commonly found in industrial and commercial installations. The unit accepts AC input from 100 to 240 volts at a frequency of 50 to 60 Hz, drawing a maximum current of 5.2 amps. It can also operate with DC input ranging from 80 to 370 volts, with a maximum current draw of 4.6 amps. The power supply delivers a steady output of 56 volts DC with a total power capacity of 480 watts, which is sufficient to power multiple high power PoE++ devices simultaneously. Built for reliability and durability, the power supply is capable of operating in temperatures ranging from -25 to 70 degrees Celsius (equivalent to -13 to 158 degrees Fahrenheit). This wide temperature tolerance makes it suitable for use in both indoor and outdoor enclosures, as well as in challenging environments where temperature conditions may fluctuate. The unit is designed for DIN rail mounting, allowing for easy installation in industrial cabinets, control panels, or other equipment racks. Its compact and rugged construction ensures long term performance and secure integration within a variety of system setups.

This high-power midspan is designed to provide reliable power to devices requiring more than standard PoE, supporting up to 60 watts of output. Fully compliant with the IEEE 802.3at standard, it is ideal for powering high-performance network devices such as advanced AXIS cameras and other High PoE-enabled equipment. The unit operates with a wide input voltage range of 100 to 240 V AC, allowing for flexible deployment in various regions and environments. Its plug-and-play design ensures quick and easy installation, requiring no additional configuration or setup. Engineered specifically to support AXIS devices with high power demands, this midspan delivers dependable performance while simplifying the power and data cabling infrastructure. It’s a cost-effective solution for extending the capabilities of your existing network without the need for PoE-enabled switches.

This device is built to be robust and reliable in industrial installations, ensuring stable performance even in demanding environments. It provides 60W of Power over Ethernet (PoE), delivering efficient power to connected devices. The device is designed to withstand extreme temperatures, with an operating range from -40°C to 75°C, or -40°F to 167°F, making it suitable for both cold and hot environments. Equipped with dual DC inputs ranging from 20V to 60V DC, it offers flexible power options and increased reliability in case of power failure. The device is widely compatible with Axis PoE devices, ensuring seamless integration into your existing system. Its plug-and-play functionality makes installation simple and quick, requiring minimal setup for immediate use.

For network or fiber installations
SFP slot for fiber
Integrated midspan
High PoE 60 W
Support for all Axis network products

The AXIS TU8002-E 90 W Outdoor PoE Midspan is built to deliver reliable, high-power performance in the most demanding outdoor environments. Designed for use with power-hungry devices like PTZ and multi-sensor cameras, it supplies up to 90 watts of PoE power, supporting IEEE 802.3af, 802.3at, 802.3bt, and Axis High PoE standards for broad compatibility. Encased in a durable, weather-resistant housing, this midspan is rated IP66/IP67 and NEMA TS2, providing exceptional protection against dust, water, and severe weather conditions. It operates in extreme temperatures ranging from -40 °C to 65 °C (-40 °F to 149 °F), making it ideal for installations in both hot and cold climates. The TU8002-E accepts a wide input voltage range of 100 to 240 V AC and meets railway standards EN 50121-4 and IEC 62236-4, ensuring it can be deployed in transportation and other mission-critical infrastructure environments. With a focus on reliability, compatibility, and rugged design, the AXIS TU8002-E is a powerful solution for outdoor surveillance systems where high power and dependable operation are essential.

The AXIS TU8003 is a high-performance 90 W connectivity midspan designed to simplify and enhance network and fiber installations, particularly in demanding surveillance environments. With support for both data and power transmission, it enables seamless integration of Axis PTZ cameras and other high-power devices. Delivering up to 90 watts of power over Ethernet, this midspan supports IEEE 802.3bt (PoE++) and AXIS High PoE standards, ensuring full compatibility with power-hungry devices such as advanced PTZ cameras, multi-sensor units, and networked peripherals. In addition to power and data, the TU8003 features integrated audio and I/O ports, allowing for two-way audio communication and flexible integration with sensors, alarms, and access control systems. This makes it a versatile solution for complex security installations. A built-in SFP slot supports fiber-optic connectivity, enabling long-distance network runs while maintaining high-speed, stable performance. The unit operates on a wide input voltage range of 100–240 V AC, making it suitable for global installations across various power infrastructures. Compact, reliable, and easy to deploy, the AXIS TU8003 is ideal for installations requiring high power, flexible connectivity, and streamlined integration with Axis network solutions.

The AXIS TU8004 is specifically designed to power high-demand network devices with efficiency and reliability. It supports both the IEEE 802.3bt standard and AXIS High Power over Ethernet (High PoE) technology, making it an ideal choice for applications that require higher power levels, such as advanced surveillance cameras and other professional network equipment. Capable of delivering up to 90 watts of power, this single-port midspan is fully compatible with AXIS devices that require high wattage for optimal performance. It provides both data and power through a single Ethernet cable, simplifying installation and reducing the need for separate electrical wiring. The device accepts a wide input voltage range of 100 to 240 volts AC, allowing it to operate efficiently in various electrical environments worldwide. This flexibility makes it suitable for a wide range of installations, from commercial buildings to critical infrastructure. Please note that the AXIS TU6011 Mains Cable, which is required for connecting the midspan to a power source, is not included and must be purchased separately.
